THE PERFECT LIGHT FOR LARGE AREAS AND HIGH DEMANDS
Lumena Fit LED is a high lumen-output wide beam 3000K projector for illuminating the industrial sector, warehouse and logistics areas and parking lots. The robust high-output projector scores with excellent quality of light, high energy efficiency (≥ 120 lm/W) and a long 100,000 hour service life.
Luminaire type
LED floodlight for wide-area illumination.
Applications
Container areas, Large building sites, Storage locations, Terminals, Power stations, Sports centres
Mounting methods
For post-top mounting. Swivel range 0°, 5°, 10, Fixed Mount for fixing the luminaire to single or multiple-configuration masts, this application must be supplemented with separately ordered accessories (cross-arms).
Optical system
With special lens optic particularly designed for wide beam applications. With asymmetrical wide light intensity distribution.
LED system
Luminaire luminous flux 120000 lm, connected load 1.100,00 W, Power Faktor λ > 0,95, luminous efficiency of luminaire 109 lm/W. Light colour warm white, correlated colour temperature (CCT) 3000 K, general colour rendering index (CRI) Ra > 70. Colour locus tolerance (initial MacAdam) ≤ 5 SDCM, Mean rated service life L80(tq 25 °C) = 100,000 h.
Luminaire body
Spotlight body of die-cast aluminium. Cover of light emission aperture of non-laminated safety glass. Colour of luminaire housing anthracite, similar to DB 703, powder-coated. (DB 703). Weight: 43,0 kg. Windage area Fw= 0,200 m². Safety class (EN 61140): I, protection rating (DIN EN 60529): IP66, impact resistance level in accordance with IEC 62262: IK08.
Electrical version
Electrical block with 6 electronic control gear units, digitally dimmable (DALI). Control gear unit according to DALI-2 standard (EN 62386). The control gear unit is replaceable in accordance with the ecodesign requirements (VO (EU) 2019/2020). Number of occupied DALI devices: 6. Order unit consists of a luminaire housing as well as a separately packaged electrical block. Surge voltage resistance 10 kV. The luminaire complies with the fundamental requirements of applicable EU regulations and product safety legislation and bears the CE symbol. The luminaire is also ENEC-certified by an independent testing authority.
Planning information:
The luminaire is compliant to the requirements of EN 60598 and is designed for the effects of wind compliant to EN 1991 (Eurocode) with basic wind velocity of up to 30m/s (corresponding to wind zone 4 in Germany) in terrain category 1. A snow load (up to 1kN/m²) and icing (up to 2 cm) at a mounting height in accordance with the mounting instructions are taken into account. Not considered are exposed locations (e.g. bridges, installation on buildings or directly adjacent to railway tracks). Impact loads are not considered.
